TECHNICAL SPECIFICATIONS: |
| Overall Length: |
2,085 mm |
| Overall Width: |
745 mm |
| Overall Height: |
1,170 mm |
| Wheelbase: |
1,430 mm |
| Ground Clearance: |
150 mm |
| Seat Height: |
800 mm |
| Dry Mass: |
187 kg |
| Fuel Capacity: |
17 litres |
 |
| |
ENGINE: |
| Engine Type: |
90-degree 4-stroke V-twin, DOHC, liquid
cooled, fuel injected, 4 valves per cylinder |
| Bore x Stroke: |
98.0 x 66.0 mm |
| Max Power: |
120 PS (88.o Kw) @ 9,000 rpm |
| Max Torque: |
102 Nm @ 7,200 rpm |
| Piston Displacement: |
996 cc |
| Compression Ratio: |
11.3 : 1 |
| Carburettor: |
Fuel injection 52 mm |
| Lubrication: |
Wet sump |
|
|
| |
ELECTRICAL SYSTEM: |
| Ignition Type: |
Digital Electronic (Transistorised) |
| Starter System: |
Electric |
|
|
| |
TRANSMISSION: |
| Clutch: |
Wet multi plate |
| Transmission: |
6-speed |
| Drive System: |
Chain |
|
|
| |
CHASSIS: |
| Front Suspension: |
Conventional 46 mm telescopic. Fully
adjsuatble |
| Rear Suspension: |
Link type, coil spring, oil
damped, fully adjustable |
| Rake/Trail: |
24.5 degrees / 99 mm |
| Front Brake: |
4-piston calipers, 310 mm dual discs |
| Rear Brake: |
Single-piston caliper, 220 mm disc |
| Front Tyre: |
120/70ZR17 |
| Rear Tyre: |
180/55ZR17 |
